Zgonic Monitor Arm

Zgonic Monitor Arm

With its innovative design and cutting edge technology, the Zgonic monitor arm sets a precedent in bringing an ergonomic experience to discerning users.

Description

With its innovative design and cutting edge technology, the Zgonic monitor arm sets a precedent in bringing an ergonomic experience to discerning users. It has highly flexible adjustments to fit you comfortably. Simple installation and high adaptability with different monitors are further testaments to its design with you in mind. The Zgonic monitor arm delivers exceptional ergonomic performance for true flexible working.

Maximise your viewing comfort and improve productivity. With its multi-adjustment capabilities including height adjustability, tilt, swivel and pivot, the Zgonic monitor arm lets you move the monitor to your desired position and collaborate with ease.

Body Colour: Black monitor arm with 3 side arm panel colour options: Black, White and Silver

Features:

  • Latest Spring Technology

Zgonic’s monitor arm spring is compressed to provide a balancing force against the monitor weight (ranging from 3 kg to 11 kg). Zgonic monitor arm allows the monitor to “float” and to be adjusted effortlessly and continuously.

  • Concealed Cables

Monitor cables are cleverly contained, retained and hidden from view with Magnetic covers complete the appealing, contemporary design.

  • Unparalleled Usability

Zgonic monitor arm is a unique “four-bar” mechanism that provides smooth and frictionless tilt to create glare-free viewing on the screen.

  • Tool-less Adjustment

Tool-less adjustment of the spring compression is achieved by winding the retractable knob which is linked to the spring via an ingenious gearbox and bevel gear system.

  • Spring Tension Indicator Gauge

Zgonic monitor arm has a spring compression gauge which allows pre-setting of the calibration, faster installation and lower labour cost.

  • Quick Release Mounts

Zgonic monitor arm offers two quick-release VESA mechanisms enabling rapid screen interchange or alternatively replacement of the screen with a laptop.

  • 180° Lock-Out

This unique feature prevents the monitor from colliding with a glass wall or privacy screen.

  • Tool-less Installation

Zgonic monitor arm has a two-piece interlocking desk clamp that provides rapid, effortless attachment to desktops with a thickness range of 18 mm to 60 mm

  • Warranty

10 year limited hardware warranty

Specifications:

  • Monitor Size Supportable: 17” to 34”

  • Monitor Weight Supportable: 3~11 kg per Monitor

  • Extended Arm Reach (from Desk Edge): 600 mm

  • Vertical Arm Adjustment Range: 290 mm

  • VESA Compliance: 75 mm² and 100 mm²

  • Arm Swivel Range (CW/CCW): 360°

  • Monitor Pivot Range: 360°

  • Monitor Tilt Range: Forward 20° / Backward 35°

  • Quick Release for VESA Attachment: For ease of monitor replacement

  • Quick Release for Mounting Attachment: For ease of transition to crossbar mounting

  • Desk Fixing Options: Top-down desk clamp

  • Standard Clamp Thickness Range: 16-33 mm / 33-50 mm

  • Cable Management: Concealed within upper and lower arm

  • Sustainability: 29% recycled and 99% recyclable content
